IN-2026-016 - Common Nettle (Urtica dioica) - Leaf (W.M.) - Stinging Trichomes

Overview

This investigation examines the surface structures of a leaf of Urtica dioica, with particular attention to the morphology and arrangement of stinging trichomes.

The aim was to observe the form, attachment, and distribution of these structures, and to compare their appearance under dry and water-mounted conditions.

Specimen & Context

• Species: Urtica dioica (Common Nettle)
• Location: Oxfordshire, UK
• Material: Fresh leaf (margin and surface regions)
• Preparation: Whole mount (dry and water mount)

The specimen represents actively growing foliage, with well-developed surface structures suitable for direct observation.

Method (Summary)

• Small portions of leaf margin were excised using a single-edged razor blade
• Specimens were mounted by two methods:
  1. Dry mount (no medium, minimal coverslip pressure)
  2. Water mount (mounted in a drop of water under coverslip)
• Coverslips were applied carefully to avoid deformation of the trichomes
• No staining was used
• Illumination was primarily transmitted light, with oblique adjustment via mirror
• In one instance, additional incident light (desk lamp) was introduced to explore surface reflection

Plate Groups

Plates


Urtica dioica leaf, W.M., stinging hairs in situ at leaf margin

Stinging Nettle (Urtica dioica)

IN-2026-016


Urtica dioica leaf, W.M., stinging hairs, slight curvature, clear taper, bulb visible

Stinging Nettle (Urtica dioica)

IN-2026-016


Urtica dioica leaf, W.M., paired stinging hairs emerging from epidermal surface

Stinging Nettle (Urtica dioica)

IN-2026-016


Urtica dioica leaf, W.M., stinging hairs arising from bulbous base

Stinging Nettle (Urtica dioica)

IN-2026-016


Urtica dioica leaf, W.M., stinging hairs under mixed illumination

Stinging Nettle (Urtica dioica)

IN-2026-016

Observations

Surface Distribution (SI-IV-001)

• Stinging hairs project outward from the leaf margin
• The shafts show slight curvature and taper evenly toward fine terminal points

Individual Hair Form (SI-IV-002)

• Individual hairs show slight curvature along the shaft
• A gradual taper from base to apex is evident
• The basal region appears expanded relative to the shaft

Emergence from Epidermis (SI-IV-003)

• Hairs arise individually from the epidermal surface
• Bases are clearly demarcated from surrounding tissue
• Adjacent hairs may occur in close proximity with similar orientation

Basal Structure (SI-IV-004)

• Each hair originates from a distinct bulbous base
• A transition is visible between the expanded base and narrower shaft
• The shaft maintains a consistent cylindrical form beyond this point

Illumination Effects (SI-IV-005)

• Under combined transmitted and incident light, hair surfaces show enhanced reflection
• Shaft contours and boundaries are accentuated
• The underlying epidermal surface becomes more apparent in reflected light

Interpretation

Stinging Trichomes

The observed structures are interpreted as stinging trichomes, specialised epidermal outgrowths characteristic of Urtica dioica.

Their form is defined by:

• A bulbous base
• A narrow, elongated shaft
• A fine, tapering terminal region

This morphology is consistent across both mounting methods.

Attachment and Orientation

The consistent emergence of hairs from discrete points on the epidermis indicates that each trichome is a distinct cellular structure.

Their outward orientation, particularly along the leaf margin, suggests a role in surface defence.

Effect of Mounting Method

Comparison of dry and water mounts shows:

• Dry mounts preserve the natural rigidity and straightness of the hairs
• Water mounts enhance visibility of internal structure and wall definition
• Minor curvature and softening of outlines may occur in water

These differences reflect the physical interaction between the specimen and mounting medium rather than changes in underlying structure.

Optical Behaviour

The introduction of oblique and mixed illumination reveals:

• Strong edge contrast along the hair walls
• Increased visibility of surface contours under reflected light

This highlights the optical properties of the hair walls, which appear smooth and refractive.

Functional Considerations

The combination of:

• Elevated position on the surface
• Slender, tapering form
• Distinct basal attachment

is consistent with a defensive function, enabling contact with external agents at the leaf surface.

Remarks

• The dry mount preparations (SI-IV-001, SI-IV-002) are particularly effective in preserving overall form
• Water mounts (SI-IV-003 to SI-IV-005) provide improved visibility of structural detail at the base and along the shaft
• The use of mixed illumination (SI-IV-005) demonstrates the value of simple optical variation in revealing surface features
• The investigation provides a clear introduction to surface structures within Series I/IV (Surface & Exchange), focusing on defensive adaptations rather than exchange processes
